Item Qty Part No. Description Notes
47 1
9315476501
ELBOW M/M 1/2" BSPP x 3/4" JIC 90°
REPLACEMENT O-RING =
9330006015
48 1
9100000063
HOSE CLAMP 2 1/4”
49 1
9100000064
HOSE CLAMP 2 3/4”
50 4
9100000062
HOSE CLAMP 21-38mm
52 1
9518000011
THERMOSTAT
53 1
9518000012
GASKET - THERMOSTAT HOUSING
55 3
9131231001
FLAT WIDE WASHER 3/8” x 1 1/4” x 16G
56 3
9111411055
HEX BOLT M10 x 55mm
57 37
9132141000
SPRING LOCK WASHER M10
58 40
9111411020
HEX BOLT M10 x 20mm
59 3
9131221000
PLAIN WASHER M8
60 3
9132221000
SPRING LOCK WASHER M8
61 11
9111311020
HEX BOLT M8 x 20mm
62 3 9111522030 SOCKET HEAD CAP SCREW M12 x 30mm
(LOCKTITED)
63 4
9111311030
HEX BOLT M8 x 30mm
64 4
9518000032
STUD M10 x 50mm
65 4
9121142000
HEX NUT M10
66 4
9122141000
NYLOC NUT M10
67 1
9111311070
HEX BOLT M8 x 70mm
68 7
9122131000
NYLOC NUT M8
69 8
9131231000
PLAIN WASHER M10
70 4
9518000021
STUD M8 x 60mm
74 4
9120131002
HEX FLANGE NUT M8 SERATED
76 2
9111311016
HEX BOLT M8 x 16mm
77 1
9001194462
3/8” HYD-HOSE REAR PUMP TO REAR
SELECTOR VALVE
78 1
9001194463
1/2” HYD-HOSE FRONT PUMP TO FRONT
SELECTOR VALVE
79 1
9001194464
1” HYD-HOSE SUCTION (535mm)
80 2
9300000006
HOSE CLAMP 34mm
81 1
9518000008
DYNAMO
82 1 OBSOLETE BUSH REDUCE 3/8"BSPT x 22mm 1.5P Was 9311330000
83 1 OBSOLETE 90° BRASS FITTING Was 9319333420
84 1
9345400000
1/2” ORTAC HOSE OIL DRAIN HOSE
85 1
9319160400
HOSE TAIL 3/4" JIC/SAE FEM x 1/2" HOSE
86 1
9312650000
PLUG 3/4"x 16 TPI ADAPTOR JIC MALE
