SK00691GB
21
ELECTRIC WIRING DIAGRAM
Centre pole/wiring harness
Control
Battery
Generator
Starter
Solenoid-Vibration
Oil pressure switch
Switch V/R
white
violet
brown
brown
blue
black
red
red
red/yellow
pink
MF800
red
violet
pink
Console
Touch contact start
Vibration
Oil pressure
Battery charge gauge
Press switch Vibration
Ignition lock
Press switc VIB
Ignition lock
Oil pressure
Battery charge gauge
Vibration
Switch
Start switch
Contactor piece
pink black
red
black
red
red
black
pink
red
pink
blue
Upper mass
AMP Mate-n-Lok
Typ „Frontplate“
12pol.
1-480709
black
Solenoid valve-forwards-
reverse travel
