E 2200, E 3000ES
Maintenance
wc_tx001670gb.fm
103
8.
Remove the exhaust stack
(e)
(both inner and ou
ter panels).
9.
V
acuum out the e
xhaust ducting
(f)
and the heater
.
10.Reinstall t
he exhaust stack.
1
1.Reassemble the machine.
Result
The procedure is now complete.
f
e
wc_gr008079
102
104
