E 2200 / E 3000ES Operation
wc_tx001667gb.fm 53
Continued from the previous page.
NOTICE: Disengage the clutch (release the foot pedal) before reaching the hose
end. Failure to do so may damage the machine.
7. Release the foot pedal to disengage the clutch approximately six feet from the
end of the hose.
8. Manually wind the remainder of the hose onto the reel.
9. Move Pump 2 ON-OFF switch to the OFF position.
10.Connect hose loop 1 to hose loop 2.
11.Move Pump 1 ON-OFF switch (e) to the ON position.
12.Rewind hose loop 1 as you did hose loop 2.
13.Move Pump 1 ON-OFF switch to the OFF position.
14.Engage the hose reel brake by turning the T-handle (a) clockwise.
15.Return the foot pedal to its storage location.
16.Move the burner ON-OFF switch (f) to the OFF position.
Result
The hoses are now wound onto the hose reel and your machine is ready to be
placed into storage. See topic Storing the Machine.
wc_gr007803
wc_gr008065
e
f
