Putting into operation 4
Figures 90 and 91 refer to work with a Wacker Neuson hydraulic hammer.
Working with another tool can result in a different work area.
Assembly
1. Stop and park the machine. Stop the engine. See “Preparing
lubrication”.
2. Tighten hexagonal bolts B(M8/8.8) to a torque of 25 Nm (18 ft./lbs.) at
the tie-down lugs A.
Information
Two people are required for assembly.
Fig. 91 (symbolic representation)
Fig. 92
A
A
Fig. 93 (symbolic representation)
B
