Wacker Neuson ET42

4-6 BA E19 en* 1.0 * E19_10_400.fm
4 Putting into operation
Opening the whole front window
1. Open the lower front window as described on page 4-5.
2. Open both windows together as described on page 4-4.
Closing the whole front window
1. Close both windows together as described on page 4-4.
2. Close the lower front window as described on page 4-5.
NOTICE
If the protective Front Guard structure is installed, the front windows can
be damaged.
► The lower front window must be fully open when the entire front
window is opened or closed (Fig. 81).
Opening the front window to a gap (ventilation position)
1. Press levers A on the left and right, and slightly pull handles B on the
left and right.
➥ The front window is unlocked.
2. Release levers A and pull handles B on the left and right until the front
window engages.
Fig. 80
Fig. 81
Fig. 82
Fig. 83
A
B
