4.30 Engine Components (all)—GP/GPS 3800A/5600A/6600A
Ref. Description Ref. Description
A Generator C Engine
B Control box D Electric start engines
Ref. Description Ref. Description
1 Idle solenoid 6 Solenoid (GPS only)
2 Fuel cut solenoid 7 Starter (GPS only)
3 Oil alert module 8 Charging coil (GPS only)
4 Oil level switch 9 Battery (GPS only)
5Coil
