Wacker Neuson LTN6L-V

wc_tx003097gb.fm
30
Operation LTN 6L-V
4.6 Control Panels
wc_gr009945
f g h k l m n vu
o
p
q
3
2
1
230VAC
a
e
a
e
b
c d
230V 115V
b
c d
Ref. Description Ref. Description
1
Floodlight control panel
h
Low oil pressure shutdown
2
Engine control panel k High coolant temp. shutdown
3
Tower switch panel l Alternator indicator
a
25A circuit breaker m Auxiliary lights (not used)
b
30A lights circuit breaker n Glow plug indicator
c
16A circuit breaker o Air filter restriction indicator
d
16A receptacle p Auxiliary lights (not used)
e
Hour meter q Key access door
f
Low fuel indicator (not used) u Tower switch (raise / lower)
g
Safety shutdown indicator v Lights rotation switch
