LTN 6L-V Maintenance
5.11 Changing the Engine Oil
When
Change the oil and oil filter (d) every 250 hours.
On new machines, change oil after first 50 hours of operation.
Requirements
Engine stopped, but still warm.
Plastic sheet
Container of suitable size to collect drained oil
Fresh engine oil (see Technical Data)
Procedures
Follow the procedure below to change the engine oil.
1. Open the doors and remove oil fill cap (a).
2. Place a plastic cloth and a collection container beneath the oil drain (b).
3. Remove the oil drain plug and open the valve (c) to drain the oil.
4. Close the valve (c) and reinstall the oil drain plug.
5. Fill engine crankcase with recommended oil until the level reaches the “MAX”
line on the dipstick (d).
6. Reinstall the oil fill cap.
This procedure continues on the next page.
wc_gr010444
b
a
wc_gr010445
c
d
To Next Page
