LTN 6L-V Schematics
Ref. Description Ref. Description Ref. Description
a Generator g Circuit breaker, 250V 16A m Capacitors, 30 µF
b Terminal strip h Battery n Light bar
c Main circuit breaker i Engine control panel s Fuel solenoid (option)
d Floodlight receptacles j Engine t Capacitor, 31.5 µF
e Receptacle, 230V 16A k Hour meter u Float switch (option)
f Circuit breaker, 250V 30A l Transformers — —
Wire Colors
BK Black RD Red YL Yellow OR Orange
GN Green TN Tan BR Brown PU Purple
BU Blue VIO Violet CL Clear SH Shield
PK Pink WH White GY Gray LB Lt. blue
