Operation RD 7
30 wc_tx000294gb.fm
4.9 Cold Weather Starting (RD 7H, RD 7H-S)
See Graphic: wc_gr001338, wc_gr001339, wc_gr001340
At temperatures below approximately -5°C (30°F), always turn the
engine over to ensure that it rotates freely.
4.9.1 Check that the exciter switch (a) is in the OFF position.
4.9.2 Pull the throttle control (c) up to open the engine throttle.
4.9.3 Move the decompression lever (f) to a position that is approximately
halfway between f0 and f1.
4.9.4 Insert the crank (d) into the guide sleeve (b).
4.9.5 Turn the crank 10 turns (rotations) to build up pressure for the engine
to fire.
4.9.6 Clean around the cover of the metering device (g), then:
• remove the cover
• fill with lubricating oil until the level reaches the upper rim
• press the cover on firmly.
4.9.7 Start the engine as normal. See section Starting the Machine.
c
c1
a
b
d
wc_gr001338
wc_gr001339
e
f0
f1
g
f
wc_gr001340
