Maintenance RD 7
52 wc_tx000295gb.fm
5.13 Hydraulic Oil Level
See Graphic: wc_gr001356
A hydraulic oil level sightglass (a) is located on the hydraulic tank and
is visible through the slots on the top cover.
Check the oil level with the machine standing on a level surface. The
oil level should be at the halfway mark on the sightglass. If the level is
low, remove the top cover and top up with hydraulic oil as necessary.
If hydraulic oil continually needs to be added, inspect the hoses and
connections for possible leaks. Repair hydraulic leaks immediately to
prevent damage to the hydraulic components.
a
wc_gr001356
