RD 7 Operation
wc_tx000294gb.fm 31
4.10 Engine Speed
During operation, run the engine at full throttle. This ensures maximum
exciter speed and will produce the best compaction.
4.11 Stopping the Machine
See Graphic: wc_gr001529
4.11.1 Place the exciter switch (a) in the OFF position.
4.11.2 Close the water control valve.
4.11.3 Push the throttle control (b) to the minimum position to stop the engine.
4.11.4 On electric start machines, turn the engine switch (c) to the OFF
position.
4.11.5 Apply the parking brake.
4.11.6 Clean the scraper bars before storing the machine.
NOTICE: Should the engine ever speed out of control and not stop by
using the throttle control, pulling up on the decompression lever, which
could be hot to the touch, will stop the engine.
