Maintenance RD 7
50 wc_tx000295gb.fm
5.11 Water Spray Bars
Background
Clogged or dirty spray bars can prevent water from spraying onto the
drums. If water spray is noticeably reduced or absent even though
there is water in the tank, then clean the spray bars.
Procedure
Follow the procedure below to clean the spray bars.
5.11.1 The spray bars (a) are located behind the drum scrapers.
5.11.2 Start the machine. Activate the spray system and check for free flow
of water through each spray hole (b).
5.11.3 If any of the spray holes are blocked, stop the machine and use a
small pointed object (i.e. a stiff piece of wire) to remove the blockage.
5.11.4 Rinse the spray bars with clean water and dry with a soft, clean cloth.
NOTICE: The cap (c) and fitting (d) are not removable.
wc_gr007078
a
a
b
a
c
d
