Maintenance RD 7

40 wc_tx000295gb.fm

Upper handle parts list

Ref. Part No. Qty. Description

Measurement

and Torque

15 0112307 1 Handle

16 0155442 1 Rod

20 0112351 1 Spring

28 0155441 1 Disc

77 0112391 2 Bearing 20 x 20

132 0010367 4 Lock nut M8

137 0010622 10 Flat washer B8,4

141 0011310 2 Hex head screw M8 x 85

25 Nm / 18 ft.lbs

145 0011346 2 Hex head screw M8 x 65

25 Nm / 18 ft.lbs
