Operating manual Piston Pump EvoMotion 5-125
14 Spare Parts
58 Order number 2316596 | Edition 03/2021
Pos K Stk Order no. Designation
6 1 A645.01 Washer
7 1 A644.12 Cylinder flange
8 4 9907079 Hexagon socket head cap screw
9 ♦ 1 D114.42A Pump rod D36
10 ♦⋆ 2 G609.08 Gasket
11 1 A646.03 Piston valve
12 1 B0344.03 Special screw M6x35
13 1 K311.03A Self-locking hexagon nut
14 1 K108.03 Hexagon socket head cap screw
15 1 A827.03 Rod coupling
16 ♦ 1 D710.22 Pump cylinder
17 1 A647.03 Pump rod
18 1 A648.03 Rod bush
19 1 A649.03 Piston valve
20 1 9913031 Self-locking hexagon nut
21 2 K317.03 Hexagon nut
22 ♦ 1 A179.03 Valve foot
23 ♦⋆ 1 L137.06 O-ring
24 ♦ 1 A650.03 Inlet housing
25 1 K604.22 Securing ring
26 1 A651.03 Valve stop
27 1 K158.03 Hexagon socket head cap screw
28 ♦⋆ 1 A253.01 Support ring
29 ♦⋆ 1 A250.01 Support ring
30 ♦⋆ 3 G121.05 Sealing collar T 36/50
31 ♦⋆ 3 G121.08E Sealing collar PE 36/50
32 1 9992831 Loctite® 542
33 1 9998808 Mobilux EP 2 grease
1 T958.00AE Service set - EvoMotion fluid section 125 cm³
♦ = wearing parts
⋆ = Included in service set
