WAGNER GA 5000EACIC - Technical Data and Dimensions

28
GA 5000EAC
OPERATING MANUAL
VERSION 09/2016 ORDER NUMBER DOC2360922
5.5 TECHNICAL DATA
Control air pressure (open product valve) 0.4–0.8 MPa; 4–8 bar; 58–116 psi
Maximum atomizing air pressure 8 bar; 0.8 MPa; 116 psi
Maximum shaping air pressure 0.8 MPa; 8 bar; 116 psi
Maximum product pressure 250 bar; 25 MPa; 3626 psi
Input voltage maximum 20 Vpp
Input current maximum 1.0 A AC
Maximum output voltage 80 kV
Maximum output current 100 µA
Polarity Negative
Maximum discharge energy 0.24 mJ
Product connection NPSM 1/4"-18
Atomizer air connection D10
Shaping air connection (only for GA 5000EACEC) D8
Control air connection D6
Weight (without houses) 1.0 kg; 2.2 lb
Flow rate
according to nozzle size
(see nozzle table in "Accessories" chapter)
Ambient temperature 0 °C - 40 °C; 32 °F - 104 °F
Maximum product temperature 50 °C; 122 °F
Maximum surface temperature 85 °C; 185 °F
Compressed air quality: free from oil and water
Quality standard 6.5.2 according to ISO 8573.1, 2010
6: Particle density ≤ 5mg/m
5: Humidity: pressure dew point ≤ +7°C
2: Oil content ≤ 0.1mg/m
Sound level at 0.3 MPa; 3 bar; 43.5 psi air pressure
and 0.3 MPa; 3 bar; 43.5 psi product pressure *
76 dB(A)
* A-rated sound pressure level measured at 1 m distance, LpA1m, in accordance with DIN EN 14462: 2005.
