WAGNER GA 5000EACIC - Electrostatic Effect

32
GA 5000EAC
"?
OPERATING MANUAL
VERSION 09/2016 ORDER NUMBER DOC2360922
Electrode
Paint particle
Object to be sprayed is
grounded
The spray gun produces an electrostatic  eld by means of the high-voltage electrode.
As a result, the paint particles atomized by the spray gun are carried to the grounded work
piece by kinetic and electrostatic energy, where they adhere  nely dispersed to the object
to be sprayed.
Advantages
- Very high application e ectiveness
- Low over spray
- Coating of entire circumferences due to the electrostatic e ect
- Savings in working time
5.6.3 ELECTROSTATIC EFFECT
