13.2.2 ACF5000 AIRCOAT FLAT JET NOZZLES
Order No. Marking Drilled hole mm; inch Spray angle
Application
395107 07/10 0.18; 0.007 10° Natural lacquer
395207 07/20 20°
395407 07/40 40°
395109 09/10 0.23; 0.009 10° Clear lacquer
395209 09/20 20° Oils
395309 09/30 30°
395409 09/40 40°
395509 09/50 50°
395609 09/60 60°
395111 11/10 0.28; 0.011 10° Synthetic resin lacquer
395211 11/20 20° PVC lacquer
395311 11/30 30°
395411 11/40 40°
395511 11/50 50°
395611 11/60 60°
395811 11/80 80°
395113 13/10 0.33; 0.013 10° Lacquers
395213 13/20 20° Base coat
395313 13/30 30° Primer
395413 13/40 40° Filler
395513 13/50 50°
395613 13/60 60°
395813 13/80 80°
395115 15/10 0.38; 0.015 10° Filler
395215 15/20 20° Rust proo ng paints
395315 15/30 30°
395415 15/40 40°
395515 15/50 50°
395615 15/60 60°
395815 15/80 80°
395217 17/20 0.43; 0.017 20° Rust proo ng paints
395317 17/30 30° Latex paints
395417 17/40 40°
395517 17/50 50°
395617 17/60 60°
395817 17/80 80°
