WAGNER GA 5000EACIC - Page 73

73
GA 5000EAC
9
1
4
5
2
6
7
3
10
SW5
SW7
SW7
SW8
B_05785
OPERATING MANUAL
VERSION 09/2016 ORDER NUMBER DOC2360922
1. Loosen clamping screw (1) with
assembly tool (5).
2. Remove valve rod unit (2, 3, 4, 6).
3. Only as required:
Remove rod seal (10).
Do not damage the housing in
the process.
