44 ProSpray 24
g
Repairs at the unit
11.4 ProSpray 24 connection diagram
Potentiometer
Motor
Pressure Sensor
Pressure Sensor
J
umper
Plug
WHITE
WHITE
WHITE
BLACK
GREEN
C
ontrol Panel
Board
S
urge
Suppressor
E
lectronic Pressure
Control (EPC)
J16
AC-Motor
A
C-NeutAC-Line
AC-Motor
J9
J2 J1
J12 J7
S
witch
Ground
1
00~120 V AC
Potentiometer
Motor
Pressure Sensor
Pressure Sensor
Jumper
Plug
BLUE
WHITE
WHITE
BROWN
GREEN
Control Panel
Board
Surge
Suppressor
Electronic Pressure
Control (EPC)
J16
AC-Motor
AC-NeutAC-Line
AC-Motor
J9
J2 J1
J12 J7
Switch
Ground
220~240 V AC
