48 ProSpray 24
gg
Accessories and spare parts
Item Order No. Description
1
0508 608
Suction hose
2
0508 605
Return hose
3 0508 738 Filter
4
9871 105
O-ring (2)
5
0279 459
Clamp
6 9822 526 Retaining clip
0551 106
Suction hose assembly
(includes items 1–6)
12.8 Spare parts list for suction system
of stand and low boy
(spare parts diagram, see Page 110)
12.7 Spare parts list of stand
(spare parts diagram, see Page 109)
Item Order No. Description
1 0508 377 Cord wrap
2 0508 586 Plug (1)
3 0551 651 Right leg (includes items 1, 2, 4, and 6)
4 0551 525 Plug (3)
5 0551 483 Clip
6 0508 660 Screw (2)
Item Order No. Description
7 0509 856 Nut
8 0507 397 Drip cup
9 0551 818 Left leg (includes items 4, 5, 7, 8, 10, and 11)
10 0551 732 Screw
11 0507 955 Screw (2)
12.6 Spare parts list for low boy cart
(
spare parts diagram, see Page 109)
Item Order No. Description
1 0551 792 Cart weldment (includes items 6 and 15)
2
0507 956 Roll pin (2)
3 0294 534 Wheel spacer (4)
4 0270 394 Wheel (2)
5
9890 104 Cap (2)
6 0551 548 Plug (2)
7 0295 615 Lock nut (2)
8 0507 955 Screw
9 0295 618 Screw (2)
10 0551 133 Mounting bracket, left
11 0551 734 Mounting bracket, right
I
tem Order No. Description
12 0295 608 Screw (4)
1
3 0295 606 Washer (4)
14 0507 397 Drip cup
15 0551 525 Plug (2)
1
6 0295 609 Handle washer (2)
17 0295 610 Roll pin (2)
18 9841 504 Snap button (2)
19 0295 607 Sleeve (2)
20 0551 793 Handle asssembly
(includes items 12, 13, and 16–19)
