WAGNER ProSpray 24 User Manual

ProSpray 24 47
g
Accessories and spare parts
Item Order No. Description
1
2 0551 648 Motor, 220~240 V AC, 50/60 Hz
0551 729 Motor, 100~120 V AC, 50/60 Hz
13 0508 572 Crankshaft
1
4 0508 573 Thrust ring
15 0507 938 Gearwheel, stage 2
16 ------------ Gear unit housing
1
7 0551 541 Connecting rod
18 0507 768 Retaining ring
12.4 Spare parts list for drive assembly
(
spare parts diagram, see Page 107)
Item Order No. Description
1
0551 614 Ventilator shroud
2 0551 616 Ventilator
3 9850 936 ON/OFF switch
4
0508 571 Screw (4)
5 0551 518 Front cover
6 0507 777 Connecting pin
7
0551 649 Pressure sensor
8 0551 650 Pressure sensor o-ring
9 0508 558 Electronic cover
10
0551 647 Electronic control assembly, 230 V AC
0551 731 Electronic control assembly, 100~120V AC
11 0551 790 Motor complete, 220~240 V AC, 50/60 Hz
(includes items 1, 2, 10, and 12)
0551 791 Motor complete, 100~120 V AC, 50/60 Hz
(includes items 1, 2, 10, and 12)
Item
Order No.
Description
9 0551 550 Plug
10 0551 548 Plug (2)
11 0295 606 Washer (6)
12 0295 608 Screw (4)
13 0507 655 Cord wrap (2)
14 0551 555 Screw (4)
15 0551 653 Cart weldment (includes items 8–10)
16 0278 373
Wheel (2)
12.5 Spare parts list for upright cart
(spare parts diagram, see Page 108)
Item Order No. Description
1 0551 652 Handle assembly
(includes items 2–5, 10 and 11
2 0295 607 Handle sleeve (2)
3 9841 504 Snap button (2)
4 0295 609 Handle washer (2)
5
0295 610 Roll pin (2)
6 9890 104 Cap (2)
7 0294 534 Spacer (4)
8
0508 586 Plug
