SPARE PARTS DIAGRAM
PS 3.25
GB SUCTION SYSTEM FOR STAND
39
1
3
2
4
5
#
PS 3.25 Description
1 0551 706 Siphon hose
2 9850 638 Tie wrap (2)
3 0558 659A Return tube
4 0279 459 Clip
5 0295 565 Inlet screen
0558 672 Siphon tube assembly (includes items
1-5)
