WAGNER T090 - Page 29

29
T090, T092.
OPERATING MANUAL
EDITION 01 /2014 PART NO. ZZB022ENG
3)()??'"

7!2.).'
)NCORRECTMAINTENANCEREPAIR
2ISKOFINJURYANDDAMAGETOTHEEQUIPMENT
 2EPAIRSANDPARTREPLACEMENTMAYONLYBECARRIEDOUTBYSPE
CIALLYTRAINEDSTAFFORA7!'.%2SERVICECENTER
 "EFOREALLWORKONTHEUNITANDINTHEEVENTOFWORKINTERRUP
TIONS
3WITCHOFFTHEENERGYCOMPRESSEDAIRSUPPLY
2ELIEVETHEPRESSUREFROMTHESPRAYGUNANDUNIT
3ECURETHESPRAYGUNAGAINSTACTUATION
 /BSERVETHEOPERATINGANDSERVICEINSTRUCTIONSWHENCARRYING
OUTALLWORK
Spare parts list
T090.00A
T090.00B
T090.00C
Pos K Description Q.ty No.
1 Lower reducer body 1 B589.22
2 Main reducer body 1 B590.22
3 Upper reducer body 1 B591.22
4

Ball seat 1 T6044.00
5 Adjustment screw 1 B594.03
6 Shutter piston 1 B595.53
7

Shutter stem 1 B619.03
8 Pressure reducer support 1 E506.62
9

Valve spring 1 H218.03A
10 Cup spring see exploded
view
H266.02
11 Ring nut M25 1 K303.62A
12

Ball 1 K813.04
13

O-ring 2 L149.06
14

Gasket 1 L418.08
15 Socket screw 8x90 6 K139.62
Seal gasket set T9062.00
= Wearing parts
= Included in seal gasket set
