WAGNER T090 - Functioning; Pressure Regulator

16
T090, T092.
3
1a
1
a
a
b
c
P1 P1
P1 P1
P1 P1
P2
P2
P2
2
1a
4
OPERATING MANUAL
EDITION 01 /2014 PART NO. ZZB022ENG
4.4 FUNCTIONING
4.4.1 PRESSURE REGULATOR
1 Product diaphragm
1a Air diaphragm
2 Piston
3 Pilot air inlet
4 Small piston
a Valve ball and seat
b Regulation spring
c Regulation knob
P1 Fluid outlet / pressure gauge
P2 Fluid inlet
General description
The  uid pressure regulator is normally used in the painting systems to assure a good  uid
pressure control to the equipment. A regulator installed on a line reduces the pressure of
the main line until reaching the pressure required by this equipment.
The working principles of pressure regulators with manual control – referring to the
section of Fig. 1 and 2 – are as follows:
Fig. 1 (T090.00A, B, C, CR, MAG) Fig. 2 (T092.00AI, BI)
Fig. 3 (T092.00PNI)
