WAGNER T090 - Page 33

33
T090, T092.
OPERATING MANUAL
EDITION 01 /2014 PART NO. ZZB022ENG
3)()??'"

7!2.).'
)NCORRECTMAINTENANCEREPAIR
2ISKOFINJURYANDDAMAGETOTHEEQUIPMENT
 2EPAIRSANDPARTREPLACEMENTMAYONLYBECARRIEDOUTBYSPE
CIALLYTRAINEDSTAFFORA7!'.%2SERVICECENTER
 "EFOREALLWORKONTHEUNITANDINTHEEVENTOFWORKINTERRUP
TIONS
3WITCHOFFTHEENERGYCOMPRESSEDAIRSUPPLY
2ELIEVETHEPRESSUREFROMTHESPRAYGUNANDUNIT
3ECURETHESPRAYGUNAGAINSTACTUATION
 /BSERVETHEOPERATINGANDSERVICEINSTRUCTIONSWHENCARRYING
OUTALLWORK
Spare parts list
T090.00MAG
Pos K Description Q.ty No.
1 Lower reducer body 1 B0252.22
2 Main reducer body 1 B590.22
3 Upper reducer body 1 B591.22
4

Ball seat 1 T6044.00A
5 Adjustment screw 1 B594.03
6 Shutter piston 1 B595.53
7

Shutter stem 1 B0253.03
8 Socket screw 8x90 6 K139.62
9 Pressure reducer support 1 E506.62
10

Valve spring 1 H224.03
11 Cup spring 25 H266.02
12
Ring nut M25 1 K303.62A
13
 
Carbide 1/2 ball 1 K823.04
14

O-ring 2 L126.06
15

Gasket 1 L418.08
16

Sliding ring 1 L835.08
Complete piston (6+7) T6174.00
Seal gasket set T9062.00AA
= Wearing parts
= Included in seal gasket set
