T090, T092.
OPERATING MANUAL
EDITION 01 /2014 PART NO. ZZB022ENG
3)()??'"

7!2.).'
)NCORRECTMAINTENANCEREPAIR
2ISKOFINJURYANDDAMAGETOTHEEQUIPMENT
 2EPAIRSANDPARTREPLACEMENTMAYONLYBECARRIEDOUTBYSPE
CIALLYTRAINEDSTAFFORA7!'.%2SERVICECENTER
 "EFOREALLWORKONTHEUNITANDINTHEEVENTOFWORKINTERRUP
TIONS
3WITCHOFFTHEENERGYCOMPRESSEDAIRSUPPLY
2ELIEVETHEPRESSUREFROMTHESPRAYGUNANDUNIT
3ECURETHESPRAYGUNAGAINSTACTUATION
 /BSERVETHEOPERATINGANDSERVICEINSTRUCTIONSWHENCARRYING
OUTALLWORK
Spare parts list
T092.00AI T092.00BI
Pos K Description Q.ty No. Q.ty No.
1 Lower reducer body 1 B640.03A 1 B640.03A
2 Ball guide 1 B637.03 1 B637.03
3

Spring 1 H261.03 1 H261.03
4

Carbide D5 ball 1 K828.04 1 K828.04
5
 
EPDM O-ring 2 L130.06 2 L130.06
6

Complete ball seat body 1 T6008.00 1 T6008.00
7

Shutter stem 1 B391.03 1 B391.03
8 Main reducer body 1 B639.03 1 B639.03
9 Product diaphragm disk 1 B641.03 1 B641.03
10
 
Diaphragm 2 G760.07 2 G760.07
11

Small piston 1 B148.03 1 B148.03
12

Intermediate  ange 1 B145.12 1 B145.12
13

Spring guide 1 B634.52 1 B634.52
14 Cup spring (see exploded view) 24 H266.02 28 H266.02
15 Upper reducer body 1 B147.12 1 B147.12
16 Ring nut M25 1 K303.62A 1 K303.62A
17 Adjustment screw 1 B594.03 1 B594.03
18 Pressure reducer support 1 E506.62 1 E506.62
19 SSt 1/4 Nipple 1 M801.03B 1 M801.03B
20 Socket screw 8x80 2 K109.62 2 K109.62
21 Socket screw M8x70 2 K193.62 2 K193.62
Seal gasket set T9061.00 T9061.00
= Wearing parts
= Included in seal gasket set
