WAGNER W 690 Flexio Original Operating Instructions

GB
32
W 690 Flexio
Spare Parts List Wall Extra I-Spray spray attachment (Fig. 25)
Pos. Designation Order No.
Wall Extra I-Spray spray attachment complete with 1800 ml
container
2361 749
1 Spray jet adjustment ring 2353 697
2 Union nut 2353 698
3 Air cap 2363 208
4 Air screen 2362 886
5 Nozzle 2328 908
6 Nozzle seal (2 pcs.) 2304 433
7 O-ring of spray attachment 2362 875
8 Ventilating hose, valve cover, diaphragm 2304 027
9 Suction tube 2328 922
10 Container seal 2328 919
11 Container with cover 1800 ml
(only for Wall Extra I-Spray spray attachment)
2304 025
Spare Parts List W 690 Flexio (Fig. 26)
Pos. Designation Order No.
1 Carrying belt 2322 299
2 Gun handle 2362 879
3 Air hose 2362 880
4 Cover of air lter compartment (right and left) 2316 052
5 Air lter (2 pcs.) 2318 585
6 Stirring rod 2304 419
7 Feed hopper (3 pcs.) 2304 028
Lubricating grease 2315 539
22. Accessories
The CLICK&PAINT SYSTEM with additional spray attachments and accessories oers
the right tool for each work.
Further information about the WAGNER range of products for renovating is available
under www.wagner-group.com

WAGNER W 690 Flexio Specifications

General

Weight	2.4 kg
Technology	HVLP
Spray Width	250 mm
Frequency	50 Hz
Container Capacity	0.9 l
Paint container volume	0.9 l
Voltage	230 V
