Sound Parameters – Low Frequency Oscillators (LFO)
Waldorf Q User’s Manual 128
Low Frequency Oscillators (LFO)
In addition to the main oscillators, the Q is equipped with three low frequency oscillators that can be
used for modulation purposes. Each LFO generates a periodic waveform with adjustable frequency
and shape.
Low Frequency Oscillator Panel Controls
The following picture of the Q’s front panel shows the LFO section:
Shape Sync
Speed Delay
Shape Sync Speed Delay
Shape Sync Speed Delay
Edit
LFOs
2
1
3
Picture 44: LFO Panel Controls Q Keyboard
The most commonly used controls of the LFO can be found on the front panel.
Selecting a LFO on the Q Rack
Press one or more LFO Select buttons to select one or more LFO on the Q Rack to be edited with the
Panel Controls.
Shape Sine / Triangle / Square / Saw / Random / S & H
Sets the type of waveform generated by the respective LFO. The following picture shows the available
shapes:
Square
S&H
Random
Triangle
Sawtooth
Sine
Picture 45: LFO Shapes
• The Sine shape is best suited for oscillator FM or pan modulations.
• The Triangle shape is perfect for smooth pitch, filter or volume modulations.
• The Square shape can be interesting for hard pan modulations or special effects.
