Sound Parameters – Mixer
83 Waldorf Q User’s Manual
N/E Select F1 / F2 Feed Noise / ExtLeft / ExtRight / ExtL+R
Sets the input signal sources that are fed into filter 1 and filter 2.
Please note that the N/E Balance control behaves differently compared to the other Balance controls.
N/E Balance only affects the input levels but doesn't move the signals between the filters. F1 Feed is
always routed to Filter 1 while F2 Feed is always routed to Filter 2.
The available sources are:
• Noise selects the Noise Generator as input for the respective filter.
110 100 1000 10000
Frequency (Hz)
Magnitude
Time
Amplitude
Picture 21: Noise
• ExtLeft selects the Left input signal as input for the respective filter.
• ExtRight selects the right input signal as input for the respective filter.
• ExtL+R feeds the summed signal of the left and right input into the respective filter.
