Wali GSMP002 - Page 9

9
Step 4
A
Put the assembled TV/Monitor onto the Arm A and ensure the stability, tighten the VESA plate using Top Screw.
Step 5
Press the Arm A on horizontal level as image shown, adjust gas spring tension to your personal preference using Allen
Key 5mm L , adjust the tilt tension using Allen Key 5mm L .
A
L
L
For Heavier Monitors
For Lighter Monitors
