Operating Instructions
40
5. Stop ground travel by pulling both steering
levers backward to the NEUTRAL position
(trac tor not moving) and then moving the FSC
lever to the NEUTRAL-PARK position.
NOTE: If the tractor creeps forward or back-
ward with the FSC lever in the NEUTRAL-
PARK position, the transmission control needs
to be adjusted. Refer to ADJUSTMENTS for
Transmission Control and Neutral Function
Adjustment in Mainte nance Instructions or con-
tact your Walker dealer.
ENGAGING THE BLADE DRIVE
1. Set the engine throttle at about 1/3 speed. Do
not attempt to engage the blade clutch at
high engine speeds. This will drastically short-
en drive belt life. Use only moderate engine
speed when engaging the blade clutch.
2. Engage the blade clutch by pulling the blade
clutch lever SLOWLY up. For disengagement,
push the blade clutch lever down SLOWLY.
Engaged
Position
Blade Clutch Engaged
Disengaged
Position
Blade Clutch Disengaged
CAUTION
An operator presence switch (seat switch)
will cause the engine to stop if the blade
clutch is engaged and the operator is not in
the seat. The function of this switch should
be checked by the op erator raising o󰀨 the
seat and engaging the blade clutch; the en-
gine should stop. If the switch is not work-
ing, it should be repaired or replaced be-
fore operating the mower. DO NOT
disconnect the safety switches; they are
for the operator’s protection.
IMPORTANT: DO NOT engage the blade clutch
when transporting the mower across drives, side-
walks, loose materials, etc. DO NOT engage the
blade clutch with the PTO shaft disconnected
(the mower deck removed from tractor).
