Walker H38i - Component Identification

Component Identication
6
Front View and Right Side View
NOTE: Control Identication
shown in Operating
Instructions section.
Body TiltUp
Latch
Deck
Caster Wheels
Deck Height
Lift Chain
Deck
TiltUp Bar
Deck Support Arm
(Not Visible)
Counterweight Springs and
Protective Covers
Adjustable
Footrest
Adjustable
Footrest
Forward Speed
Control (FSC)
Friction
Adjustment
Deck Lift Foot Pedal
(Raises Deck)
Cutting Height Release Lever
(Cutting Height Adjustment)
Deck Support Arm
(Not Visible)
TiltUp Latch
Deck TiltUp
Socket
TiltUp
Hook
