Walker H38i - Drive Belts; Seat; Frame;Body Construction; Deck Chart

Specications
5
MODEL H38i
DIMENSIONS (continued)
Weight lb (kg)
Tractor Only 802 (364)
Tractor with 64" Rear Discharge
Deck (DR643)
1239 (562)
DRIVE BELTS
Engine PTO Walker P/N 2230 (Set of 3)
Ground Drive Walker P/N 22481
SEAT Full Spring Suspension with Dampening and Adjustments for
Back Angle, Lumbar Support, and Operator Weight.
Includes Adjustable/Retractable Armrests
FRAME/BODY CONSTRUCTION
Frame All Welded Unitized Steel Chassis
Body 14 Gauge Steel
Deck 11 Gauge Steel
DECK DR52 DS60 DR64
Type Belt Driven,
Rear Discharge
Belt Driven,
Side Discharge
Belt Driven,
Rear Discharge
Cutting Width in. (cm) 52 (132) 60 (152) 64 (163)
Cutting Height in. (cm) 1 to 5 (2.5 to 13)
Height Adjustment in. (cm) 1/4 (1) Increments, 17 Positions
Blade Length in. (cm) 18.4 (47) 20.5 (52) 22.2 (56)
Number of Blades 3
Direction of Rotation
(Viewed from top of deck)
Clockwise
Deck Suspension TorsionFlex Frame with Caster Wheels and Counterweight Springs
Maximum Blade RPM 3840 3330 3200
Maximum Blade Tip Speed
ft/min (m/min)
18500 (5640) 17870 (5460) 18500 (5639)
NOTE: The manufacturer reserves the right to make changes in specications shown herein at any time
without notice or obligation. The specications listed are for a standard conguration tractor, and may
change with the addition of optional equipment.
