Walter Surfox 203 - C) Wand Control Buttons; D) Fume Elimination System

C) WAND CONTROL BUTTONS
The ON butt
The ON butt
on is used to give power to the Tungsten tip. When the pumping mode is set to manual,
press the
ON button to activate the pump.
ON button to activate the pump.
Press and keep the button pressed to get continuous flow of liquid.
How
How
ever, if the pumping mode is set to automatic, press the ON button once to activate the pump. To stop the
pump, press the OFF button. When finished working with the machine (in either mode) make sure to press
pump, press the OFF button. When finished working with the machine (in either mode) make sure to press
the
the
OFF button.
Once the ON button is pressed, there will be continuous power at the tip until the OFF button is pressed.
Once the ON button is pressed, there will be continuous power at the tip until the OFF button is pressed.
D
) FUME ELIMINATION SYSTEM (PATENTED)
The
Surfox 203
machine comes with the integrated fume elimination system. This system provides for better
working conditions. Although the fumes are non-toxic and non hazardous, they can be uncomfortable when
working conditions. Although the fumes are non-toxic and non hazardous, they can be uncomfortable when
working in confined areas.
working in confined areas.
To activate this feature simply connect a compressed air line (150 PSI max., 80 PSI min.) to the fitting at the
To activate this feature simply connect a compressed air line (150 PSI max., 80 PSI min.) to the fitting at the
back of the machine. The fume elimination system is automatically activated when the ON button is pressed on
back of the machine. The fume elimination system is automatically activated when the ON button is pressed on
the Hand Wand. The fume elimination system is turned OFF when the OFF button on the Hand Wand is
the Hand Wand. The fume elimination system is turned OFF when the OFF button on the Hand Wand is
pressed.
pressed.
I
f the fume elimination system is not wanted, simply disconnect the compressed air line.
The working principle is quite simple and highly effective; the air comes out through the small openings behind
The working principle is quite simple and highly effective; the air comes out through the small openings behind
the Tungsten tip. This preset regulated air pressure condenses the vapors out of the air.
the Tungsten tip. This preset regulated air pressure condenses the vapors out of the air.
8
Tungsten tip
Tungsten tip
ON
OFF
III -
EQUIPMENT CONTROLS
Small openings
Compressed
air line fitting
