Walther Systemtechnik S11 series User Manual

Rev. 1.4
Assembly Instructions – Spray Valve SMS-11
Page 21 of 28
Walther Systemtechnik GmbH – D 76726 Germersheim
Telefon: +49 (0)7274-7022-0 Telefax: +49 (0)7274-7022-91
http://www.walther-2000.de – info@walther-2000.de
9.2.1 Spare Part List for SMS-11 (Standard)
Fig.-No.
Article-No.
Qty
Description
1.0
97410028
1
Collar ring
2.0
*
1
Air cap, flat-spray, ø 20 x 14.5mm
2.1
*
1
Air cap, round-spray, ø 20 x 11mm
3.0
*
1
Nozzle, stainless steel, ø 12 x 18mm
4.0
97510345
1
Main body SMS-11, stainless steel, complete
5.0
97810054
1
Sealing sleeve, complete
5.1
97640155
1
Variseal
5.2
97640317
1
O-Ring / Viton®
5.3
97810053
1
Sealing sleeve
5.4
97640316
2
O-Ring / Viton®
5.5
97640026
1
O-Ring / Viton®
6.0
*
1
Nozzle needle, complete
6.1
97640007
1
O-Ring / Viton®
7.0
97820076
1
Pressure spring
8.0
97320318
1
Raster screw
9.0
97511021
1
Cover plate, complete
9.1
97511020
1
Cover plate 30 x 30 x 10mm
9.2
97610017
2
Threaded pin DIN 913
9.3
97820077
2
Pressure spring
9.4
97650004
2
Ball, stainless steel
10.0
97610055
2
Countersunk screw DIN 7991
11.0
97320668
1
Regulating knob, stainless steel, complete
11.1
97610034
1
Threaded pin DIN 915
12.0
97380032
1
Throttling screw, complete
12.1
97380033
1
Throttling screw
12.2
97640364
1
O-Ring / Viton®
13.0
97220300
1
Locking screw, stainless steel 1/8"
14.0
97610249
1
Threaded pin DIN 915
15.0
97610339
1
Screw joint M5, complete, with sealing
16.0
97220022
3
Straight screw-in screw joint 1/8" - 6/4 KU
* Article numbers can be found on the following pages.
IMPORTANT
Always indicate the inscribed serial numbers when ordering spare parts!
