Walther Systemtechnik S11 series User Manual

Rev. 1.4
Assembly Instructions – Spray Valve SMS-11
Page 23 of 28
Walther Systemtechnik GmbH – D 76726 Germersheim
Telefon: +49 (0)7274-7022-0 Telefax: +49 (0)7274-7022-91
http://www.walther-2000.de – info@walther-2000.de
9.3.1 Spare Part List for SMS-11 (Raster-Needle Sensor)
Fig.-No.
Article No.
Qty
Description
1.0
97410028
1
Collar ring
2.0
*
1
Air cap, flat-spray, diam. 20 x 14.5mm
2.1
*
1
Air cap, round-jet, diam. 20 x 11mm
3.0
*
1
Nozzle, stainless steel, diam. 12 x 18mm
4.0
97510345
1
Main body SMS-11, stainless steel, complete
5.0
97380032
1
Throttling screw, complete
5.1
97640364
1
O-ring / Viton®
5.2
97380033
1
Throttling screw
6.0
97810054
1
Retainer, complete
6.1
97640155
1
Variseal
6.2
97640317
1
O-ring / Viton®
6.3
97640316
2
O-ring / Viton®
6.4
97810053
1
Retainer
6.5
97640026
1
O-ring / Viton®
7.0
*
1
Nozzle needle, complete
7.1
97640007
1
O-ring / Viton®
8.0
97820076
1
Pressure spring
9.0
97511494
1
Cover plate, complete
9.1
97320923
1
Sensor spindle, complete
9.1.1
97320820
1
Raster screw, diam. 13 x 23.5mm, stainless steel
9.1.2
97320317
1
Regulating spindle carrier, st.steel, 7 x 7.5mm
9.1.3
97820074
1
Pressure spring 0.60 x 6.70mm
9.1.4
97320670
1
Sensor holder, st.steel, 7 x 18mm, complete
9.2
97511020
1
Cover plate, 30 x 30 x 10.5mm
9.3
97650004
2
Ball, stainless steel
9.4
97820077
2
Pressure spring
9.5
97610017
2
Threaded pin DIN 913
9.6
97320821
1
Regulating knob, diam. 19 x 10mm, stainless steel
9.7
97610034
1
Threaded pin DIN 915
10.0
97610055
2
Countersunk screw DIN 7991
11.0
97610249
1
Threaded pin DIN 915
12.0
97220300
1
Locking screw, stainless steel, 1/8"
13.0
97610339
1
Locking screw M5, complete with sealing
14.0
97220022
3
Straight screw-in screw joint 1/8" - 6/4 KU
* Article numbers are indicated on the following pages.
IMPORTANT
Always indicate the inscribed serial numbers when ordering spare parts!
9.4 Wear-and-Tear Parts
Wear-and-Tear Parts Kit complete for SMS-11 (Standard)
1
Article-No.
Description
97640319
Wear Parts Kit for SMS-11, VITON
1
We recommend this wear-and-tear kit when exchanging nozzle needles and nozzle.
