Assembly Instructions – Spray Valve SMS-11
Page 26 of 28
Walther Systemtechnik GmbH – D 76726 Germersheim
Telefon: +49 (0)7274-7022-0 Telefax: +49 (0)7274-7022-91
http://www.walther-2000.de – info@walther-2000.de
3.0
Nozzle, special spin, stainless steel (Ø12x18mm)
Article No.
Description
97210483
Nozzle, special spin, 0.2mm
97210484
Nozzle, special spin, 0.3mm
97210482
Nozzle, special spin, 0.5mm
97210485
Nozzle, special spin, 0.8mm
97211030
Nozzle, special spin, 1.0mm
97212510
Nozzle, special spin, 1.5mm
97212397
Nozzle, special spin, 2.0mm
9.7 Article Numbers for Nozzle Needles
9.0
Nozzle needle complete, standard and marking,
Special spin, VITON
Article-No.
Description
97110884
Nozzle needle, Standard, 0.2/0.3mm
97110885
Nozzle needle, Standard, 0.5mm
97110886
Nozzle needle, Standard, 0.8mm
97110887
Nozzle needle, Standard, 1.0mm
97110888
Nozzle needle, Standard, 1.2mm
97110889
Nozzle needle, Standard, 1.5mm
97110890
Nozzle needle, Standard, 2.0mm
97110891
Nozzle needle, Standard, 2.5mm
9.0
Nozzle needle complete, KLS, VITON
Article-No.
Description
97110900
Nozzle needle, KLS, 0.2/0.3mm
97110901
Nozzle needle, KLS, 0.5mm
97110902
Nozzle needle, KLS, 0.8mm
97110903
Nozzle needle, KLS, 1.0mm
97110904
Nozzle needle, KLS, 1.2mm
97110905
Nozzle needle, KLS, 1.5mm
97110906
Nozzle needle, KLS, 2.0mm
97110907
Nozzle needle, KLS, 2.5mm
9.8 Screw Joints
6.0
Straight screwed joint for material and air
Article-No.
Description
97220022
Straight screwed joint with nut SW 13x28mm /1/8-6/4 (Standard)
97220243
Straight screwed joint with nut SW 13x28mm /1/8-8/6
