9.5 Article Numbers for Air Caps
2.0
Air cap, Flat-jet, Standard, 60° (Ø20x14.5mm)
Article-No.
Description
97310234
Air cap, Flat-jet, 0.2-1.0mm
97310235
Air cap, Flat-jet, 1.2-1.5mm
97310236
Air cap, Flat-jet, 1.8-2.0mm
97310237
Air cap, Flat-jet, 2.5mm
2.0
Air cap, Flat-jet, Standard, 90° (Ø20x14.5mm)
Article-No.
Description
97310238
Air cap, Flat-jet, 0.2-1.0mm
97310239
Air cap, Flat-jet, 1.2-1.5mm
97310240
Air cap, Flat-jet, 1.8-2.0mm
97310241
Air cap, Flat-jet, 2.5mm
2.0
Air cap, Flat-jet, KLS, 60° (Ø20x14.5mm)
Article-No.
Description
97310242
Air cap, Flat-jet, KLS 0.2-1.0mm
97310243
Air cap, Flat-jet, KLS 1.2-1.5mm
97310244
Air cap, Flat-jet, KLS 1.8-2.0mm
97310245
Air cap, Flat-jet, KLS 2.5mm
2.0
Air cap, Flat-jet, KLS, 90° (Ø20x14.5mm)
Article-No.
Description
97310246
Air cap, Flat-jet, KLS 0.2-1.0mm
97310247
Air cap, Flat-jet, KLS 1.2-1.5mm
97310248
Air cap, Flat-jet, KLS 1.8-2.0mm
97310249
Air cap, Flat-jet, KLS 2.5mm
2.1
Air cap, Round-jet, Standard, 15° (Ø20x11mm)
Article-No.
Description
97310034
Air cap, Round-jet, 0.2-1.0mm
97310035
Air cap, Round-jet, 1.2mm-1.5mm
97310080
Air cap, Round-jet, 1.8-2.0mm
97310091
Air cap, Round-jet, 2.5mm
2.1
Air cap, Round-jet, KLS, 15° (Ø20x11mm)
Article-No.
Description
97310084
Air cap, Round-jet, KLS 0.2-1.0mm
97310085
Air cap, Round-jet, KLS 1.2-1.5mm
97310086
Air cap, Round-jet, KLS 1.8-2.0mm
97310250
Air cap, Round-jet, KLS 2.5mm
