Overview
9
Waltron User Manual 101-016-B.3
3041 Silica Analyzer
1 OVERVIEW
1.1 SPECIFICATIONS
1.1.1 PERFORMANCE
Sensor Classification:
Colorimetric with glass flowcell and LED source
Application:
Demineralized, boiler, potable, surface and waste
water
Power Supply:
110-220Vac, 50-60 Hz 80 VA
Humidity:
Up to 90% not condensable
Ambient Temperature Range:
10-45º C analyzer (50-113º F)
Range:
0 – 500ppb, 0 – 5ppm, 0 – 150ppm*, 0 – 300ppm*
*By Auto Dilution
Accuracy:
+/– 1 ppb or +/– 2% of reading, whichever is greater
Unit Dimensions:
Height=23.6”(60 cm), Width=15”(38 cm),
Depth=8.3”(21 cm)
Positioning and Installation
Details:
Wall mounting or with bench support, panel mount
optional
Response Time (approx.):
12min, batch process, programmable cycle frequency
Alarms:
2 or 4 configurable alarm relays
Reproducibility:
+/– 1 ppb or +/– 2% of reading, whichever is greater
Degree of Protection:
IP55 (NEMA 4): Wet section, IP65 (NEMA 4x):
Electronics
Required Maintenance:
Monthly replenish reagents, Quarterly replace tubing
Reagent Consumption
(approx.):
3 reagents, 2.5L each per month (optional 7.5L for 3
months)
Materials in Contact with
Sample:
Glass, Silicone, Plexiglass, Stainless Steel AISI 316
CE Certification (on request):
Meets low voltage and low electromagnetic
compatibility directives
Sample Conditioning
Requirements:
Filtering between 10 and 60 micron, depending on the
matrix, needed only to avoid clogging
Weight:
17 kg
1.1.2 SAMPLE OPERATING CONDITIONS
Temperature Range:
5-55º C (41-131º F)
Inlet Sample:
100–500 ml/min, atmospheric, flexible tubing I.D. ¼” (6 mm)
Outlet Sample:
Atmospheric, waste tubing O.D. 3/8” (9 mm)
Turbidity:
Not applicable, sample blank correction
Color:
Not applicable, sample blank correction
PH:
3-12
