CHAPTER 4
INSTALLATION
3402
This section contains the information necessary to unpack and install the
5536 workstation.
4.1 INCOMING INSPECTION
When the equipment arrives, immediately locate the packing slip and note
the work order number. Verify the equipment model and serial number as
listed on the packing slip.
Before opening the container, inspect it carefully for signs of damage
(crushed edges, puncture holes, tears, etc.). Should damage be noted,
promptly file a claim with the carrier and notify the factory:
WLI DISTRIBUTION CENTER
Department 4f90
Quality Assurance Department
Tewksbury, MA 01876
State the nature and extent of damage and make arrangements for replacement
equipment, if necessary. Be certain to include this information:
WORK ORDER ff
CUSTOMER NAME
CUSTOMER #
MODEL #
SERIAL #
4. 2 UNPACKING
5536 workstations are packaged in a single cardboard
packaging material for protection during shipping.
other components are installed at the factory.
4.3 WORKSTATION INSPECTION
Remove the workstation cover as follows:
container with special
Circuit boards and
o Remove the three phillips screws located under the plastic strip on the
keyboard and remove the keyboard plate.
o Remove one phillips screw from each side of the workstation near the
lower edge of the cover.
o Lift the cover up and away from the workstation; take care not to hit or
nick the CRT, or strain the brightness/contrast wires.
o Remove the brightness/contrast wires from the clamp on the side of the
cover. Lay the cover on its side next to the workstation.
4-1
