7.1 INTRODUCTION
CHAPTER 7
ILLUSTRATED PARTS BREAKDOWN
3402
This section contains the illustrated parts breakdown for the 5536
workstation. Use this IPB to identify parts during removal/replacement,
alignment, and adjustment procedures; when troubleshooting or performing
PM; or when ordering parts. The following chart indicates page and figure
numbers for the major workstation subassembl ies. The parts breakdown for
PCBs is located in Chapter 6 (Schematics). Each schematic contains its
own component layout and part number listing information.
SUBASSSEMBLY PAGE NO.
FIGURE NO.
External Cover Assembly
7-2 7-1
12" Monitor Assembly 7-4
7-2
Motherboard/Chassis 7-6 7-3
Power Supply Assembly 7-8
7-4
NOTE
All items followed by a § indicate an FCC-approved part.
All parts replacement or repair on installations completed
after 10/1/83 must use FCC-approved parts. Older install-
ations may use either part number if there is a choice .
