INITIAL
OPERATIONAL
CHECK-OUT
o
Turn
both
the
master
and
workstation
POWER
switches
ON.
The
workstation
CRT
raster
should
appear
after
about
thirty
seconds,
along
with
the
works
ta
ti
on
ma
in
menu.
Should
the
menu
not
appear,
adjust
the
BRIGHTNESS
and
CONTRAST
controls
on
the
front
panel
of
the
workstation
(figure
4-5).
NOTE
Should
you
encounter
difficulty
obtaining
a
raster
and/or
menu,
refer
to
Chapter
8
of
this
manual
for
troubleshooting
procedures.
o Use
the
diagnostics
listed
in
section
1.3.1
to
check
the
ability
of
the
workstation
to
operate
properly.
o
Replace
the
cover.
CAUTION
When
replacing
the
cover,
don't
forget
to
connect
the
fan
power
cable
and
ground
wire.
4.5
TELECOMMUNICATION
OPTION
OPERATION
4.5.1
SWITCH
SETTINGS
The 210-7541
PCA
has
one
DIP
labeled
SWl.
The
switches
on
the
DIP
are
used
to
address
the
TC
device.
These
addresses
should
be
even
values
from
2
thru
22
(decimal),
where
switch
1
is
the
least
significant
bit
and
switch
5
is
the
most
significant
bit.
Figure
4-6
shows
the
switch
settings
for
the
first
TC
workstation
on a
line
with
a
diagram
showing
the
relationship
between
the
switch
and
its
corresponding
binary
and
decimal
values.
Figure
4-6
should
be
used
as
an
aid
in
setting
the
switches
for
the
remaining
TC
workstations
on a
line.
Other
workstations
with
TC
use
the
following
format:
the
switches
are
set
in
binary
for
even
line
numbers;
the
second
workstation
switches
will
be
set
to
binary
4;
the
third
to
binary
6
and
the
last
to
binary
32.
4.5.2
INSTALLATION
If
the
workstation
has
been
ordered
with
the
teleconnnunications
(TC)
option,
a 210-7541
PCA
will
have
been
installed
and
tested
at
the
factory.
o
Connect
the
TC
cable
between
the
TC
connector
on
the
rear
of
the
workstation
(figure
4-4),
and
to
the
appropriate
modem.
o
Set
the
TC
option
switch
on
the
210-7545
PCA
(figure
4-4).
o
Set
the
switches
on
the
210-·7541
PCA
as
described
in
section
4.5.1.
o
Ensure
that
the
proper
software
has
been
loaded
into
the
system.
4-6
•
•
•
