Wang 5536 - Page 91

•
•
•
BBS
Ao-A15
AC
0
-Ac6
AET
AR
0
-AR4
ARC
7
-ARC
10
AUTO RESET
BLA
BPF
BUS
BUSAK
BUSRQ
Co-C6
C4
CDO
CE
CE
0
-CE3
CHAR*
CHAR VIDEO
CI
CICL
CK*
CLICK
CLKWS
CPE
D
0
-D
DAX
7
DBA
DBUSRQ
DKf.
DLE
DL RESTART
DLS
DPARE
DRC
EDK
EDL
+GA
+GB
HB
HS
APPENDIX B
MNEMONICS
Eig}. t bit strobe
ZBOA address bits
Column Memory Address (CRT Memory)
Keyboard repeat key function
Row Memory Address (CRT Memory)
Row/Column Address (CRT Memory)
Automatic Reset caused by power
turn ON
Blank CRT screen
Bad Parity Flip-Flop
Busy signal
Busy Acknowledge
Bus Request
Column Character Count
Refresh Logic Clock
Chip Select Drive Memory Bank 0
Chip enable for CRT memory
Chip Enable Memory Bank 0-3
Selecc R/W Character (CRT Memory)
Character Video Display Dots to CRT
Character Inhibit
Character-In Clear
CRT clock
Keyboard clicker
CRT parity error detected
Eight bit system data bus
Keystroke acknowledge
Data
Bus Request
Data
Link
Error
Data
Link
Restart
Data
Link
Strobe
Data
Parity Error
Data
read clock
Enable Data Link
Horizontal blanking
Horizontal sync
B-1
3402
