2.5.2 ‘Easy Fit’ High Level Balanced Flue (HLBF)
The HLBF is available in 4 fixed horizontal lengths which are:
Option 1 – 455mm
Option 2 – 655mm
Option 3 – 585mm
Option 4 – 785mm
2.5.4 Standard Low Level Conventional Flue (LLF)
The factory supplied elbow may be extended up to 1m horizontally and 1.5m vertically
by welding on additional pipe or by using vitreous enamelled flue pipe.
2.5.3 ‘Easy Fit’ Telescopic Low Level Conventional Flue (LLF-R)
