WarmFlow COMBI 70 - Installation of Flues

6.3 Installation of Flues
OPTIONAL
EXTENSION PIECES
Easy Fit Vertical
Balanced
Flue (VBF)
Easy Fit High
Level Balanced
Flue (HLBF)
Standard Low
Level Conventional
Flue (LLF)
Easy Fit Low Level
Conventional Flue
(LLF-R)
Easy Fit
Balanced Flue
(BF-R)
Easy Fit High
Level Balanced
Flue (HLBF-R)
RIELLO RDB
BURNER
AIR INTAKE
COVER
AIR INTAKE
ADAPTER
SPIGOT &
GASKET
BOILER LID
CONVENTIONAL
FLUE RING
HORIZONTAL
FLUE ADAPTOR
FLUE TERMINAL
TOP PANEL
TEST HOLE
PLUG
FLUE
GASKET
OPTIONAL FLUE
DRESSING RING
TOP PANEL
BLANKING PLATE
Page 29
