WarmFlow COMBI 70 - 13 Spares; Riello RDB Burner

13.0 Spares
13.1 Riello RDB Burner
NO CODE 3748757 DESCRIPTION
16 3008654 • Pump
17 3007162 • ‘O’ Ring
18 3008653 • Filter ‘O’ Ring
19 3003602 • Connector
20 3005720 • Flexible
21 3008644 • Tube
22 3008876 • Pressure Gauge
23 3000443 • Joint
24 3008648 • Coil
25 3008650 • Motor
25 3002836 • Motor
26 3008649 • Protection
27 3008652 • Control Box 535 RSE/LD
28 3008877 • Lead Coil
29 3008879 • Cover
30 3008878 • Kit Seal
NO CODE 3748757 DESCRIPTION
1 3005787 • Gasket
2 3006384 • Flange
3 3008769 • Cup-shaped Head
4 3007513 • Electrode Assembly
5 3006552 • Electrode Bracket
6 3008642 • Nozzle Holder
7 3008643 • Collar
8 3008794 • High Voltage Lead
9 3008647 • Air Damper Assembly
10 3008645 • Fan
11 3008646 • PE Cell
12 3007479 • Capacitor 4
µF
12 3002837 • Capacitor 4
1
/2µF
13 3007582 • Needle Valve
14 3008651 • Regulator
15 3000439 • Pump Seal
Note: The 4
1
/2µF capacitor is only suitable for use with the 3002837 motor and the 4µF capacitor is only suitable
for use with the 3008650 motor.
Page 47
