1.5.8 K-Series Kabin Pak – Pumped (KPHE) – Key Components
1. Heat Exchanger 2. Condensing Unit 3. Pipework Assembly 4. Pressure Relief Valve 5. Auto Air Vent 6. Circulating Pump 7. Auto Air Vent 8. Service Door 9. ‘Dual-Safe’ Thermostat 10. Heat Exchanger Baffles 11. Service Door 12. Service Door Cover 13. Condensate Trap 14. Riello RDB 2.2 Burner 15. Heating Flow Connection 16. Heating Return Connection
1
8 2
45
6 7 9
10
11
12
13
14
15
16
3
Models up to 120 HE 150 HE Models
1
11
12
10
2
8
9
7
4
6
5
15
13
14
16
3
1. Heat Exchanger 2. Condensing Unit 3. Pipework Assembly 4. Pressure Relief Valve 5. Auto Air Vent 6. Circulating Pump 7. Auto Air Vent 8. Service Door 9. ‘Dual-Safe’ Thermostat 10. Heat Exchanger Baffles 11. Service Door 12. Service Door Cover 13. Condensate Trap 14. Riello RDB 3.2 Burner 15. Heating Flow Connection 16. Heating Return Connection
