1.5.9 K-Series Kabin Pak – System (KSHE) – Key Components
1. Pumped (KPHE) Boiler Assembly
2. System Kit (SK1)
3. Pressure Gauge
4. Expansion Vessel
5. Filling Loop
6. Heating Flow Connection
7. Heating Return Connection
1.5.10 K-Series Kabin Pak – Combi (KCHE) – Key Components
1. Heat Exchanger
2. Heat Store
3. Condensing Unit
4. Service Door
5. Pipework Assembly
6. Plate Heat Exchanger
7. Twin Head Pump
8. Condensate Trap
9. Service Door
10. Service Door Cover
11. Control Panel
12. Expansion Vessel
13. Riello RDB 2.2 Burner
14. Heat Exchanger Baffles
6
7
4
2
3
5
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
